बैच मिक्स प्लांट

Short Specification of 120 tph to 160 tph मोबाइल Asphalt Batch Mix Plant मोबाइल Asphalt Batch Mix Plant Capacity: 120 tph to 160 tph Key Specifications: - Mixer Capacity: 1500 kg to 2000 kg - Batch Weight: 1200 kg to 1600 kg - Drying Drum: 2.5 m to 3.5 m diameter - Burner: 20-30 million kcal/hr - Fuel: Diesel/LDO - Control System: PLC/Computerized - Power: 300-400 HP - Dimensions: 25m x 12m x 6m (approx.)

Plant Capacity - 64 TPH - 80 TPH - 100 TPH - 120 TPH - 140 TPH - 160 TPH - 200 TPH - 240 TPH Cold Aggregate Feeder - Number of Bins: 4/6 - Bin Capacity: 10-20 tons - Feeder Type: Step-type/Individual Drying Drum - Diameter: 1.8-2.5 meters - Length: 6-10 meters - Heat Source: Fuel oil/gas/natural gas Mixing Tower - Type: Batch-type - Mixer Capacity: 1-2 tons - Mixing Time: 45-60 seconds Asphalt Tank - Capacity: 10-30 tons - Type: Insulated tank with heating system - Heat Source: Fuel oil/electricity Control Panel - Type: PLC-based control panel - Features: Automatic temperature control, automatic asphalt flow control, automatic aggregate flow control Electrical Requirements - Power: 250-750 kW - Voltage: 380-440V - Frequency: 50-60 Hz Fuel Consumption - Fuel Type: Fuel oil/gas/natural gas - Fuel Consumption: 10-30 liters per hour
